Centrifugal Cabinet Fan – VBIC/T Series

The VBIC Series Insulated rectangular duct fan. Very low profile design. Backward curved centrifugal impeller. Casing manufactured from heavy gauge galvanised sheet steel. 50mm thickness of M0 glass fibre internal acoustic insulation.

External rotor motor, speed controllable, IP55, Class F insulation. External wiring terminal box. Safety thermal overload protection. Working air temperature up to 60ºC.

Available, depending upon the model, with single phase or three phase motors in 4 or 6 poles. Motors All the motors are IP55, Class F(1) insulation, with thermal protection (2).



Product category : Centrifufal Cabinet Fan
